Specification Document: Titan Truck Overland Vehicle

Overview

The Titan Truck Overland Vehicle is a high-performance, expedition-grade vehicle designed for long-range, off-grid overland travel. Built to endure the harshest environments, it combines rugged durability, advanced technology, and comprehensive comfort to support extended journeys.

General Specifications

Vehicle Type

• Class: Heavy-duty overland expedition vehicle
• Chassis: Reinforced off-road truck chassis
• Drivetrain: Full-time 4x4 with lockable differentials

Dimensions

• Length: Approx. 26 feet (8 meters)
• Width: Approx. 8.5 feet (2.6 meters)
• Height: Approx. 12 feet (3.7 meters)
• Wheelbase: 16 feet (4.9 meters)
• Ground Clearance: 18 inches (45.7 cm), adjustable with air suspension
• Weight (GVWR): 25,000 lbs (11,340 kg)

Performance

• Engine: 6.7L Turbo Diesel I6 producing 370 HP and 850 lb-ft of torque
• Transmission: Heavy-duty 6-speed with manual override and differentials
• Range: 1,200 miles (1,930 km) with extended fuel tanks
• Top Speed: 70 mph (113 km/h)
• Towing Capacity: 15,000 lbs (6,800 kg)

Fuel System

• Fuel Type: Diesel
• Fuel Capacity: 570 litres with dual tanks
• Auxiliary Fuel Option: Optional 50-gallon auxiliary tank

Suspension

• Front and Rear: Multi-link coil spring suspension with adjustable air ride
• Shock Absorbers: Dual monotube shocks with external reservoirs
• Sway Bars: Disconnectable electronic sway bars for off-road manoeuvrability

Tires

• Size: 41-inch off-road tires on bead lock rims
• Spare Tires: Two full-size spares included
• Tire Pressure Monitoring System: Integrated with auto-inflation/deflation system

Exterior Features

Body Construction

• Military-grade aluminium and steel composite for durability and weight savings
• Rust-resistant undercoating and weatherproof seals

Lighting

• LED light bar (50 inches) on the roof
• Integrated floodlights and spotlights
• Full LED headlights and taillights

Recovery and Utility

• Heavy-duty front and rear winches (18,000 lbs capacity)
• Recovery points integrated into the chassis
• Built-in snorkel for water crossings
• Roof rack with 1,000 lbs capacity
• Side-mounted recovery tracks

Storage

• Lockable exterior storage compartments
• Ladder-accessible rooftop storage and deck
• Tool storage with organizer

Interior Features

Living Quarters

• Sleeps: 4 adults comfortably
• Materials: Marine-grade plywood and aluminium panels
• Flooring: Vinyl plank for durability and ease of cleaning
• Windows: Double-glazed with UV and thermal insulation

Kitchen

• Induction cooktop
• 85-liter dual-zone fridge/freezer
• Stainless steel sink with water filtration system
• Microwave oven
• Ample cabinetry for food storage

Bathroom

• Full shower
• Composting toilet
• Hot water system (on-demand)

Seating

• Adjustable, heated driver and passenger seats
• Convertible dinette with integrated seating

Storage

• Overhead cabinets and under-bed compartments
• Integrated storage for tools and personal gear

Electrical System

Power Generation

• Solar: 1,500W solar array with MPPT charge controller
• Alternator: High-output alternator integrated with vehicle engine
• Shore Power: 120/240V input

Battery System

• 12 kWh Lithium-Ion battery bank
• Redundant battery monitoring and management system

Power Outlets

• 12V, USB, and 110V AC outlets throughout the interior
• External 110V outlets for outdoor appliances

Lighting

• Dimmable LED lighting
• Task lighting in kitchen and work areas

Climate Control

• Diesel-powered heater
• 12,000 BTU rooftop air conditioner
• Thermally insulated cabin for extreme climates
• Ventilation fans with bug screens

Safety and Navigation

Safety Features

• ABS and traction control
• Adaptive cruise control
• Lane departure warning
• Integrated fire suppression system
• First aid kit and emergency supplies

Navigation

• GPS navigation system with off-road mapping
• Satellite communication system
• Weather monitoring and altimeter
• Compass and Inclinometer

Optional Add-Ons

• Rooftop tent for additional sleeping capacity
• 360-degree camera system
• Additional water tanks (100 gallons)
• Side awning with mosquito netting
• Hydraulic levelling system

This specification ensures the Titan Truck is a versatile, robust, and comfortable vehicle for overland expeditions in all terrains and climates.
